INSTALLATION INSTRUCTION - DRILLLING
NIMCO general illustrated assembly instructions.
The product includes screws and dowels. It can be used in concrete and cladding, which has a thickness of up to 8 mm.
Correct combination of dowels and screws for:
CONCRETE - dowel diameter 6, screw min. 3.5 * 40mm
BRICK - dowel diameter 6, screw min. 3.5 * 40mm
RIGIPS - dowel fastening to plasterboard and hollow materials diameter 6mm, dowel lenght 35mm, screw 3.5 * 40mm
FLOOR - dowel and screw - MUST be used with thickness of the given tiles (pavement)
Common assembly errors!
-drilling between joints
-using the wrong size (diameter and length) of dowels and screws
-using the wrong drill size
-clogged hole after drilling
-the dowel used protrudes above the cladding. The dowel must be flush with the cladding. Otherwise, the product will not stick to the tile and it will warp!
- the product will not be attached to the wall in one plane if the holes are drilled incorrectly
